Cobham Explorer 510 BGAN Portable Satellite Internet Terminal

$3,295.00 USD

Shipping calculated at checkout.

A few left in stock!
Inventory on the way

EXPLORER BGAN is a series of L-band satellite terminals utilizing the BGAN network from Inmarsat. An EXPLORER BGAN terminal offers a broadband connection and telephony service from anywhere in the world. Every terminal features easy set-up and operation. Simply connect a PC or phone, point the terminal towards a satellite using the compass and sound indicator, and you are instantly connected from anywhere in the world.

Beyond Limits: The EXPLORER 510's Power-Packed Features.

Ultra-Portable Design: Smaller than a laptop.
High-Speed Data: Up to 464 kbps (download) and 448 kbps (upload).
Voice Calling: Supports high-quality voice calls.
Wi-Fi Hotspot: Creates a Wi-Fi hotspot with a range of up to 100 meters (330 feet).
Rugged and Robust: IP66 rated for dust and water resistance.
Global Coverage: Operates on the Inmarsat BGAN network, providing satellite connectivity worldwide (excluding extreme polar regions).
Long Battery Life: Built-in rechargeable Lithium-ion battery.
Easy Setup: Simple to deploy.

Explorer 510: Your Compact Global Hotspot

Measuring smaller than a laptop and weighing a mere 1.4 kg (3.1 lbs), the Cobham Explorer 510 redefines portable connectivity. This incredibly compact satellite terminal empowers you with a personal Wi-Fi hotspot wherever your adventures take you, ensuring you're always connected to the world, no matter how remote your location.

Built Tough for Any Terrain: The Explorer 510's Unyielding Durability

Don't let its compact size fool you – the Cobham Explorer 510 is engineered for resilience. Encased in a rugged magnesium shell and boasting an IP66 rating, this terminal is built to withstand dust, water, and the rigors of challenging environments. Whether you're facing a desert sandstorm or an unexpected downpour, the Explorer 510 is designed to keep you connected, proving that powerful technology can indeed be tough enough for any adventure.

Global Connectivity, Right from Your Pocket: The Explorer 510's Worldwide Reach

The Cobham Explorer 510 unlocks a world of connectivity. Access the internet, make calls, and send data from virtually anywhere on Earth, with coverage spanning continents and oceans (excluding extreme polar regions). Whether for remote fieldwork, emergency communications, or staying in touch on far-flung expeditions, the Explorer 510 ensures reliable, global satellite communication is always within reach.

SPECIFICATIONS

TECH SPECS

General Specifications

Dimensions (H x W x D)

202 mm x 202 mm x 51.8 mm / 7.8 in x 7.8 in x1.6 in

Weight (incl. battery)

1.4kg / 3.1lbs

Data capabilities

Standard IP: Up to 464 kbps

Streaming IP: 32, 64, 128 kbps

Voice capabilities

Standard voice: 4 kbps

Premium voice: 3.1 kHz audio, 64 kbps

Inmarsat frequencies

1518.0 - 1525.0 MHz (Rx) (EMEA) / 1525.0 - 1559.0 MHz (Rx) / 1626.5 - 1660.5 MHz (Tx) / 1668.0 - 1675.0 MHz (Tx) (EMEA)

EIRP

15.1 dBW Â±1dB

User interface

Two LED (WLAN, Status), 1 Power Button USB Host, Cobham web interface

Languages

ENG, FR, DE, ES, RU, JP and CN

Approvals

CE, FCC, IC, C-TICK Inmarsat Class 2 Type Approval

Environmental

Temperature

Operational (ambient): -25Â°C to +55Â°C / -13Â°F to +131Â°F

Storage: -25Â°C to +80Â°C / -13Â°F to +176Â°F

Battery storage temperature

1 month: -20Â°C to +60Â°C / -4Â°F to +140Â°F

3 months: -20Â°C to +45Â°C / -4Â°F to +113Â°F

1 year: -20Â°C to +25Â°C / -4Â°F to +77Â°F

Relative humidity

95% non-condensing at +40Â°C/+104Â°F

Robustness

0.5 m/1.64 ft drop on concrete (operational, 95% survival)

Water and dust

IP-66 Compiant

Power

DC input range

10.5-32VDC

Power consumption

Standby / transmit: 2.8W / 19W (typical)

During charging: 20W (max.)

Connector type 2.5mm EIAJ RC-5320-IV

AC/DC power supply

Input: 100-240VAC, 47-63Hz, 64W

Output: 19VDC

Built-in Battery

Lithium ion (rechargeable)

Stand-by time

24h, 0Â°C to 55Â°C / +32Â°F to +131Â°

Standard call

Minimum 3h (TBC)

Receive time, max.

4h40m @ 128kbps

Transmit time, max.

2h25m @ 128kbps

Recharge time

Less than 3 hours

Charge temperature

0Â°C to 45Â°C / +32Â°F to +113Â°

Interfaces

WLAN Access Point

Standard: IEEE 802.11 b/g/n

1 x USB host interface

Version: 2.0 (host)

Charging: Up to 1A

BGAN SIM-Card slot

1

BGAN Airtime

Prepaid and Postpaid Plans

Monthly

	BGAN 24/7 Emergency	Standard	Pro 30	Pro 100	Pro 250	Pro 500
Subscription Fee	$1,224/ Year	$100/ Month	$125/ Month	$350/ Month	$540/ Month	$850/ Month
Contract Term	12 Months	12 Months	3 Months	3 Months	3 Months	3 Months
Included Data	24 MB/ Year	7.8 MB/ Month	25 MB/ Month	79 MB/ Month	196 MB/ Month	391 MB/ Month
Data Overage	$8.14/ MB	$6.40/ MB	$4.95/ MB	$4.25/ MB	$2.75/ MB	$2.15/ MB
Voice Rates Fixed	$1.00/ Minute	$1.00/ Minute	$0.70/ Minute	$0.70/ Minute	$0.70/ Minute	$0.70/ Minute
Voice Rates Cellular	$1.30/ Minute	$1.30/ Minute	$0.88/ Minute	$0.88/ Minute	$0.88/ Minute	$0.88/ Minute
Voice Rates Voicemail	$0.80/ Minute	$0.80/ Minute	$0.70/ Minute	$0.70/ Minute	$0.70/ Minute	$0.70/ Minute
Voice Rates BGAN/SBB/GSPS	$0.76/ Minute	$0.76/ Minute	$0.70/ Minute	$0.70/ Minute	$0.70/ Minute	$0.70/ Minute
SMS	$0.50/ Message	$0.50/ Message	$0.45/ Message	$0.45/ Message	$0.45/ Message	$0.45/ Message

	Other Rates
32 kbps Streaming	$3.60/ Minute
64 kbps Streaming	$6.90/ Minute
128 kbps Streaming	$12.00/ Minute
176 kbps Streaming	$17.00/ Minute
256 kbps Streaming	$20.70/ Minute
BGAN HDR Half Channel / 64k	$20.70/ Minute
BGAN HDR Half Channel Symmetric	$28.00/ Minute
X Stream	$29.00/ Minute
BGAN HDR Full Channel / 64k	$32.00/ Minute
BGAN HDR Full Channel Symmetric	$38.00/ Minute

$50 Activation Fee.
Streaming services available for all plans; appropriate equipment required.

Flex Plans

	Flex 1GB	Flex 2.5GB	Flex 5GB	Flex 10GB
Subscription Fee	$1,225/ Month	$1,595/ Month	$2,375/ Month	$3,100/ Month
Contract Term	3 Months	3 Months	3 Months	3 Months
Included Data	1 GB/ Month	2.5 GB/ Month	5 GB/ Month	10 GB/ Month
Data Overage	-	-	-	-
Voice Rates Fixed	$1.00/ Minute	$1.00/ Minute	$0.70/ Minute	$0.70/ Minute
Voice Rates Cellular	$1.30/ Minute	$1.30/ Minute	$0.88/ Minute	$0.88/ Minute
Voice Rates Voicemail	$0.80/ Minute	$0.80/ Minute	$0.70/ Minute	$0.70/ Minute
Voice Rates BGAN/SBB/GSPS	$0.76/ Minute	$0.76/ Minute	$0.70/ Minute	$0.70/ Minute
SMS	$0.50/ Message	$0.50/ Message	$0.50/ Message	$0.50/ Message

	Other Rates
32 kbps Streaming	$3.60/ Minute
64 kbps Streaming	$6.90/ Minute
128 kbps Streaming	$12.00/ Minute
176 kbps Streaming	$17.00/ Minute
256 kbps Streaming	$20.70/ Minute
BGAN HDR Half Channel / 64k	$20.70/ Minute
BGAN HDR Half Channel Symmetric	$25.19/ Minute
X Stream	$25.62/ Minute
BGAN HDR Full Channel / 64k	$27.72/ Minute
BGAN HDR Full Channel Symmetric	$34.64/ Minute

$50 Activation Fee.
The BGAN Flex Plans are intended to alleviate concerns about "bill shock" by providing a plan that has the maximum "overage" charges capped for Standard IP usage. Only Standard IP services will be capped. All other services will be charged in addition to the monthly
subscription(s) at Standard Plan rates
As the Inmarsat network is a contended network, Inmarsat employs a Fair Use Policy to ensure that all users behave in a responsible way to ensure that they benefit from access to the network. This includes limitations on usage of high bandwidth applications or activities to ensure that the network remains accessible. Service Aware Control & Charging (SAC-C) will be used on the BGAN Flex Plans to support traffic management enabling the QoS to be significantly reduced if user exceeds the allowance.
Plans and Prices are not available for the US Government market.

Standard+ Plan

	Standard+
Monthly Subscription Charge	$75
Contract Term	12 Month
Included Data	20 MB
Voice Calls Fixed (Per Minute)	$1.00
Voice Calls Cellular (Per Minute)	$1.30
Voice Calls BGAN/GSPS/SBB (Per Minute)	$0.76
Voice Calls FBB (Per Minute)	$3.00
SMS (Per Message)	$0.50

	Other Rates
32 kbps Streaming	$3.60/ Minute
64 kbps Streaming	$6.90/ Minute
128 kbps Streaming	$12.00/ Minute
176 kbps Streaming	$17.00/ Minute
256 kbps Streaming	$20.70/ Minute
BGAN HDR Half Channel / 64k	$20.70/ Minute
BGAN HDR Half Channel Symmetric	$28.00/ Minute
X Stream	$29.00/ Minute
BGAN HDR Full Channel / 64k	$32.00/ Minute
BGAN HDR Full Channel Symmetric	$38.00/ Minute

Data Used	Additional Usage Fees
21 MB - 50 MB	$84
51 MB - 100 MB	$292
101 MB - 250 MB	$500
251 MB - 500 MB	$834
501 MB - 1 GB	$1,250
1 GB - 2.5 GB	$1,667
2.5 GB - 5 GB	$2,500
5 GB - 10 GB	$3,334
10 GB - 30 GB	$5,000

$50 Activation Fee
Streaming services available for all plans; appropriate equipment required.
Flex Plan is restricted to land use only.

Max

	Max 30GB	Max 60GB	Max 90GB
Subscription Fee	$1,150/ Month	$1,300/ Month	$1,389/ Month
Contract Term	12 Months	12 Months	12 Months
Included Data (In Region)	30 GB/ Month	60 GB/ Month	90 GB/ Month
Data Overage	-	-	-
Voice Rates Fixed	$1.00/ Minute	$1.00/ Minute	$1.00/ Minute
Voice Rates Cellular	$1.30/ Minute	$1.30/ Minute	$1.30/ Minute
Voice Rates Voicemail	$0.80/ Minute	$0.80/ Minute	$0.80/ Minute
Voice Rates BGAN/SBB/GSPS	$0.76/ Minute	$0.76/ Minute	$0.76/ Minute
SMS	$0.50/ Message	$0.50/ Message	$0.50/ Message

	Other Rates
32 kbps Streaming	$3.60/ Minute
64 kbps Streaming	$6.90/ Minute
128 kbps Streaming	$12.00/ Minute
176 kbps Streaming	$17.00/ Minute
256 kbps Streaming	$20.70/ Minute
BGAN HDR Half Channel / 64k	$20.70/ Minute
BGAN HDR Half Channel Symmetric	$28.00/ Minute
X Stream	$29.00/ Minute
BGAN HDR Full Channel / 64k	$32.00/ Minute
BGAN HDR Full Channel Symmetric	$38.00/ Minute

$50 Activation Fee
BGAN Max Plans and Prices are not available for the US Government market or the Global Government market.

Regional

	South America*	China
Subscription Fee	$50/ Month	$50/ Month
Contract Term	12 Months	12 Months
Included Data (In Region)	9.0 MB/ Month	9.0 MB/ Month
Data Overage In Bundle, In Region	$5.55/ MB	$5.55/ MB
Data Overage Out of Bundle, In Region	$2.92/ MB	$3.75/ MB
Data Overage Out of Region	$7.50/ MB	$7.50/ MB
Voice Rates Fixed	$1.00/ Minute	$1.00/ Minute
Voice Rates Cellular	$1.00/ Minute	$1.00/ Minute
Voice Rates Voicemail	$0.80/ Minute	$0.80/ Minute
Voice Rates BGAN/SBB/GSPS	$0.76/ Minute	$0.76/ Minute
SMS	$0.50/ Message	$0.50/ Message

	Other Rates
32 kbps Streaming	$3.60/ Minute
64 kbps Streaming	$6.90/ Minute
128 kbps Streaming	$12.00/ Minute
176 kbps Streaming	$17.00/ Minute
256 kbps Streaming	$20.70/ Minute
BGAN HDR Half Channel / 64k	$20.70/ Minute
BGAN HDR Half Channel Symmetric	$28.00/ Minute
X Stream	$29.00/ Minute
BGAN HDR Full Channel / 64k	$32.00/ Minute
BGAN HDR Full Channel Symmetric	$38.00/ Minute

$50 Activation Fee
Streaming services available for all plans; appropriate equipment required.
*South America consists of Argentina, Belize, Bolivia, Brazil, Chile, Colombia, Costa Rica, Ecuador, El Salvador, French Guiana, Guatemala, Guyana, Honduras, Mexico, Nicaragua, Panama, Paraguay, Peru, Suriname, Trinidad & Tobago, Uruguay, and Venezuela.

Prepaid

	Price	Validity Period
30 Day Extension	$49	30 Days
5.5 MB Voucher	$125	90 Days
55 MB Voucher	$375	180 Days
110 MB Voucher	$750	365 Days
275 MB Voucher	$1,750	365 Days
550 MB Voucher	$3,450	365 Days

Vouchers may also be used for voice calls
Voice call expiry rate is 9.1 minutes per MB
